This panel mount solid state relay offers 4 -32VDC input control, with a switched output rated at 30VDC/ 100Amps. Switching high current DC loads normally requires use of a contactor to avoid arcing as the contacts try to separate. This solid state relay uses MOSFET technology to provide an economical and reliable method of switching medium to high power DC loads. This means there is no arcing and the low on-state resistance provides a viable alternative to the bulky and expensive contactors.
Note: Inductive loads must have diode suppression (Refer data sheet wiring diagram)
Output Circuit
Load Voltage: 0-30VDC
Load Current: 0.02-100A
Max On-State Resistance: 0.007Ohms
Max On-State Voltage Drop: 0.35V
Max Turn On Time: 0.5ms
Max Turn Off Time: 0.5ms
Max Surge Current: 240A (10ms)
Input Circuit
Control Voltage: 4-32VDC
Control Current: 28mA max.
Min Turn Off Voltage: 1
Product Specifications
- DC Voltage : 3V, 32V
- DC Current Draw : 28mA
- Mounting Method : Chassis
- Attachment / Securing Method : Screw Down
- Mount Screw Quantity : 2pc
- Mount Screw Size : 2mm
- Overall Screw Spacing (H) : 47.5mm
- Device Type : Solid State Relay
- Input : DC
- Contact format : SPST
- DC Contact Voltage : 0V, 30V
- DC Switching Current (Closing) : 0.02A, 100A
- Operation Time : 0.5ms
- Release Time : 0.5ms
- Length : 6.3 cm
- Width : 5.1 cm
- Height : 2.9 cm
